Since there is only one screen on a Brain and it is always connected, you can take a Screen directly from Peripherals.

let mut screen = peripherals.screen;

Great! Now we have a screen, but how do we draw to it?

Drawing to the Screen

Currently, there are three options for drawing to the screen:

• vexide’s Screen API
• Slint
• embedded-graphics

Each option has some drawbacks and advantages so I’ll give a description of all three.

Screen

The Screen API is the simplest to use, and carries no additional runtime cost or external libraries. It’s also the most limited, however.

Here is some example code:

{...}
#![no_std]#![no_main]use vexide::prelude::*;
use vexide::devices::{screen::*, color::Rgb};#[vexide::main]async fn main(peripherals: Peripherals) {    let mut screen = peripherals.screen;        let rectangle = Rect::from_dimensions((50, 50), 25, 25);    let text = Text::new("Hello, World!", (100, 50));        screen.stroke(&rectangle, Rgb::WHITE);    screen.fill(&text, Rgb::LIME);}

The basic flow is creating shapes and text which you then draw using the fill and stroke functions. A few basic drawables are supported, such as:

• Rectangles
• Circles
• Lines
• Individual Pixels
• Monospace Text (in three different sizes)

Slint

Slint is a fully fledged third-party UI library that you can use with vexide. If you are coming from PROS, you can think of it as being equivalent to LVGL. Slint is by far the most powerful option out of the three choices, but also the heaviest.

To use Slint you have to enable the slint feature on the vexide crate. This can be done by editing your Cargo.toml:

[dependencies]vexide = "0.3.0"vexide = { version = "0.3.0", features = ["slint"] }slint = { version = "1.5.1", default-features = false, optional = true, features = [    "compat-1-2",    "unsafe-single-threaded",    "libm",    "renderer-software",] }

…then in your main function you have to call the initialize_slint_platform function for Slint to function properly.

{...}
#![no_std]#![no_main]use vexide::prelude::*;
use vexide::graphics::slint::initialize_slint_platform;#[vexide::main]async fn main(peripherals: Peripherals) {    initialize_slint_platform(peripherals.screen);}

embedded-graphics

embedded-graphics is a simple crate for drawing graphics to LCD screens on embedded hardware. It has many existing supporting libraries and is easy to setup and use.

In order to use embedded-graphics you have to enable the embedded-graphics feature on the vexide crate.

[dependencies]vexide = "0.3.0"vexide = { version = "0.3.0", features = ["embedded-graphics"] }embedded-graphics = "0.8.1"

From there we can create a BrainDisplay from our Screen peripheral, which acts as a display driver implementing DrawTarget in the embedded_graphics crate.

{...}
#![no_std]#![no_main]use vexide::prelude::*;
use vexide::graphics::embedded_graphics::BrainDisplay;#[vexide::main]async fn main(peripherals: Peripherals) {    let display = BrainDisplay::new(peripherals.screen);}
